          Kirchgeorg Werkzeugmaschinen GmbH - Stockist for used machines

          Machinelist:


          Center Lathe

          used  Center Lathe ANSELMI Mono 180 EA


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-19969 · Center Lathe

          ANSELMI - Mono 180 EA - - unbekannt -

          Technical details
          turning diameter over bed 410 mm︱turning diameter over slide rest 210 mm︱turning length 1000 mm︱center height over bed 205 mm︱centre distance 1000 mm︱bed width 270 mm︱digital readout 3-Achsen SINO︱spindle bore 40 mm︱turning speed range 36 - 1800 U/min︱3-jaw-chuck diameter 200 mm︱quick change toolholder RABE Typ E︱taper in tailstock-quill MK 3 ︱dia. of quill 50 mm︱quill stroke 190 mm︱voltage 380 V︱weight of the machine ca. 1,6 t︱dimensions of the machine ca. 2,20 x 0,80 x 1,50 m︱
          - 3-ixs digital readout SINO - quick change tool holder RABE - fixed steady rest - rapid clamping boring chuck
            turning diameter over bed 410 mm
            turning diameter over slide rest 210 mm
            turning length 1000 mm
            center height over bed 205 mm
            centre distance 1000 mm
            bed width 270 mm
            digital readout 3-Achsen SINO
            spindle bore 40 mm
            turning speed range 36 - 1800 U/min
            3-jaw-chuck diameter 200 mm
            quick change toolholder RABE Typ E
            taper in tailstock-quill MK 3
            dia. of quill 50 mm
            quill stroke 190 mm
            voltage 380 V
            weight of the machine ca. 1,6 t
            dimensions of the machine ca. 2,20 x 0,80 x 1,50 m
            Description :
            - 3-ixs digital readout SINO
            - quick change tool holder RABE
            - fixed steady rest
            - rapid clamping boring chuck
          Datasheet
          Request / Contact
          used  Center Lathe ZMM-SLIVEN CU 1250 x 3000


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20121 · Center Lathe

          ZMM-SLIVEN - CU 1250 x 3000 - - 2007 -

          Technical details
          turning diameter over bed 1320 mm︱turning diameter over slide rest 940 mm︱turning length 3000 mm︱center height over bed 625 mm︱turning diameter in the gap 1500 mm︱centre distance 3000 mm︱bed width 700 mm︱spindle bore 155 mm︱spindle taper KK 15 DIN 55027︱turning speed range 5 - 1000 U/min︱power requirement 22 kW︱3-jaw-chuck diameter 630 mm︱quick change toolholder 4 fach Stahlhalter ︱taper in tailstock-quill MK 6 ︱dia. of quill 125 mm︱quill stroke 260 mm︱voltage 400 V︱total power requirement 30 kW︱weight of the machine ca. 8,5 t︱dimensions of the machine ca. 5,25 x 2,05 x 1,95 m︱
          - Fabr.No.: 36937 - rapid traverse - electr. adjustable tail stock
            turning diameter over bed 1320 mm
            turning diameter over slide rest 940 mm
            turning length 3000 mm
            center height over bed 625 mm
            turning diameter in the gap 1500 mm
            centre distance 3000 mm
            bed width 700 mm
            spindle bore 155 mm
            spindle taper KK 15 DIN 55027
            turning speed range 5 - 1000 U/min
            power requirement 22 kW
            3-jaw-chuck diameter 630 mm
            quick change toolholder 4 fach Stahlhalter
            taper in tailstock-quill MK 6
            dia. of quill 125 mm
            quill stroke 260 mm
            voltage 400 V
            total power requirement 30 kW
            weight of the machine ca. 8,5 t
            dimensions of the machine ca. 5,25 x 2,05 x 1,95 m
            Description :
            - Fabr.No.: 36937
            - rapid traverse
            - electr. adjustable tail stock

          Datasheet
          Request / Contact
          used  Center Lathe BOEHRINGER DUE 800 / 2000


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20260 · Center Lathe

          BOEHRINGER - DUE 800 / 2000 - - 1986 -

          Technical details
          turning diameter over bed 820 mm︱turning diameter over slide rest 515 mm︱turning length 2.270 mm︱center height over bed 400 mm︱centre distance 2400 mm︱digital readout 3-Achsen HEIDENHAIN︱bed width 560 mm︱spindle taper KK 11 DIN 55027︱spindle bore 128 mm︱turning speed range 7,1 - 1.400 U/min︱power requirement 30 kW︱3-jaw-chuck diameter 400 mm︱quick change toolholder MULTIFIX Typ D︱taper in tailstock-quill MK 6 ︱dia. of quill 125 mm︱quill stroke 250 mm︱coolant ︱voltage 380 V︱weight of the machine ca. 6,5 t︱dimensions of the machine ca. 4,90 x 1,85 x 1,90 m︱
          - Serial - Nr.: 1042 4071 07 - digital readout HEIDENHAIN - rapid traverse - 3-jaw-self-centering wedge bar Chuck RÖHM - quick change tool holder MULTIFIX - chuck guard - fixed steady - div. Tool Holder - coolant equipment - machine lamp
            turning diameter over bed 820 mm
            turning diameter over slide rest 515 mm
            turning length 2.270 mm
            center height over bed 400 mm
            centre distance 2400 mm
            digital readout 3-Achsen HEIDENHAIN
            bed width 560 mm
            spindle taper KK 11 DIN 55027
            spindle bore 128 mm
            turning speed range 7,1 - 1.400 U/min
            power requirement 30 kW
            3-jaw-chuck diameter 400 mm
            quick change toolholder MULTIFIX Typ D
            taper in tailstock-quill MK 6
            dia. of quill 125 mm
            quill stroke 250 mm
            voltage 380 V
            weight of the machine ca. 6,5 t
            dimensions of the machine ca. 4,90 x 1,85 x 1,90 m
            Description :
            - Serial - Nr.: 1042 4071 07
            - digital readout HEIDENHAIN
            - rapid traverse
            - 3-jaw-self-centering wedge bar Chuck RÖHM
            - quick change tool holder MULTIFIX
            - chuck guard
            - fixed steady
            - div. Tool Holder
            - coolant equipment
            - machine lamp
          Datasheet
          Request / Contact
          used  Center Lathe PADOVANI Labor 180 S


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-19745 · Center Lathe

          PADOVANI - Labor 180 S - - 1985 -

          Technical details
          turning diameter over bed 360 mm︱turning diameter over slide rest 205 mm︱turning length 1000 mm︱center height over bed 180 mm︱turning diameter in the gap 580 x 240 mm︱centre distance 1000 mm︱bed width 250 mm︱spindle bore 51 mm︱turning speed range 46 - 1750 U/min︱power requirement 3,0 kW︱quick change toolholder MULTIFIX Typ B︱taper in tailstock-quill MK 4 ︱dia. of quill 52 mm︱quill stroke 170 mm︱coolant ︱voltage 400 V︱total power requirement 3,5 kW︱weight of the machine ca. 1,4 t︱dimensions of the machine ca. 2,30 x 0,90 x 1,40 m︱
          - Serial-No.: 107257 - quick change tool holder - coolant equipment
            turning diameter over bed 360 mm
            turning diameter over slide rest 205 mm
            turning length 1000 mm
            center height over bed 180 mm
            turning diameter in the gap 580 x 240 mm
            centre distance 1000 mm
            bed width 250 mm
            spindle bore 51 mm
            turning speed range 46 - 1750 U/min
            power requirement 3,0 kW
            quick change toolholder MULTIFIX Typ B
            taper in tailstock-quill MK 4
            dia. of quill 52 mm
            quill stroke 170 mm
            voltage 400 V
            total power requirement 3,5 kW
            weight of the machine ca. 1,4 t
            dimensions of the machine ca. 2,30 x 0,90 x 1,40 m
            Description :
            - Serial-No.: 107257
            - quick change tool holder
            - coolant equipment
          Datasheet
          Request / Contact
          used  Center Lathe EX-CELL-O DLZ500SL


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-19981 · Center Lathe

          EX-CELL-O - DLZ500SL - - 1962 -

          Technical details
          turning diameter over bed 500 mm︱turning diameter over slide rest 310 mm︱turning length 1000 mm︱center height over bed 250 mm︱centre distance 1045 mm︱bed width 410 mm︱spindle bore Ø 65 mm︱turning speed range 22,4 - 1120 U/min︱power requirement 7,5 kW︱3-jaw-chuck diameter 250 mm︱quick change toolholder IDEAL ︱taper in tailstock-quill MK 5 ︱dia. of quill 80 mm︱quill stroke 175 mm︱coolant ︱voltage 380 V︱total power requirement 8,0 kW︱weight of the machine ca. 2,8 t︱dimensions of the machine ca. 2,55 x 1,10 x 1,50 m︱
          - serial-no.:430 / 4 - quick change tool holder - div. tool holder - coolant equipment - machine lamp
            turning diameter over bed 500 mm
            turning diameter over slide rest 310 mm
            turning length 1000 mm
            center height over bed 250 mm
            centre distance 1045 mm
            bed width 410 mm
            spindle bore Ø 65 mm
            turning speed range 22,4 - 1120 U/min
            power requirement 7,5 kW
            3-jaw-chuck diameter 250 mm
            quick change toolholder IDEAL
            taper in tailstock-quill MK 5
            dia. of quill 80 mm
            quill stroke 175 mm
            voltage 380 V
            total power requirement 8,0 kW
            weight of the machine ca. 2,8 t
            dimensions of the machine ca. 2,55 x 1,10 x 1,50 m
            Description :
            - serial-no.:430 / 4
            - quick change tool holder
            - div. tool holder
            - coolant equipment
            - machine lamp
          Datasheet
          Request / Contact

          CNC Lathe - Inclined Bed Type

          used  CNC Lathe - Inclined Bed Type BOEHRINGER NG 200 / Sinumerik 840 D


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-19191 · CNC Lathe - Inclined Bed Type

          BOEHRINGER - NG 200 / Sinumerik 840 D - - 2001 - Sinumerik 840 D SIEMENS

          Technical details
          turning diameter 290 mm︱turning length 850 mm︱control Sinumerik 840 D SIEMENS︱swing diameter 434 mm︱travel -x axis 220 mm︱travel -z axis 950 mm︱spindle bore 65 mm︱spindle turning speed range 4.500 U/min︱turret head 12 Pos.︱tool taper VDI 40 DIN 69880︱spindle taper A6 DIN 55026︱feed speeds 25.000 mm/min︱rapid speed 25 m/min︱taper in tailstock-quill SK 30 DIN 2079︱tailstock adjustment 740 mm︱power requirement 36 kW︱coolant ︱chip conveyor ︱voltage 400 V︱total power requirement 60 kvA︱
          - S/N: 1130.2058 - 30 - control: SIEMENS Sinumerik 840 D - superfinish device LÖSER type 106 - chip conveyor - coolant equipment - Machine is not ready for operation. Machine was in a production line with post-process measuring device. The measuring device is integrated in the PLC but is no longer available! Modification of the PLC program necessary!
            turning diameter 290 mm
            turning length 850 mm
            control Sinumerik 840 D SIEMENS
            swing diameter 434 mm
            travel -x axis 220 mm
            travel -z axis 950 mm
            spindle bore 65 mm
            spindle turning speed range 4.500 U/min
            turret head 12 Pos.
            tool taper VDI 40 DIN 69880
            spindle taper A6 DIN 55026
            feed speeds 25.000 mm/min
            rapid speed 25 m/min
            taper in tailstock-quill SK 30 DIN 2079
            tailstock adjustment 740 mm
            power requirement 36 kW
            voltage 400 V
            total power requirement 60 kvA
            Description :
            - S/N: 1130.2058 - 30
            - control: SIEMENS Sinumerik 840 D
            - superfinish device LÖSER type 106
            - chip conveyor
            - coolant equipment
            - Machine is not ready for operation.
            Machine was in a production line
            with post-process measuring device.
            The measuring device is integrated in
            the PLC but is no longer available!
            Modification of the PLC program necessary!
          Datasheet
          Request / Contact

          CNC Turning- and Milling Center

          used  CNC Turning- and Milling Center GILDEMEISTER CTX 410 V3 / Sinumerik 840 D


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20283 · CNC Turning- and Milling Center

          GILDEMEISTER - CTX 410 V3 / Sinumerik 840 D - - 2006 - Sinumerik 840 D Shop Turn

          Technical details
          turning diameter 320 mm︱turning length 600 mm︱control Sinumerik 840 D Shop Turn︱C - Axis main spindle 0,04 °︱driven Tools 4.500 U/min︱3-jaw-chuck diameter 215 mm︱swing diameter 505 mm︱bar diameter 75 mm︱travel -z axis 635 mm︱travel -x axis 250 mm︱rapid travel - longitudinal/face 24 / 30 m/min︱spindle speed: 25 - 5000 1/min︱spindle bore 87 mm︱turret head 12 Pos. VDI 30︱taper in tailstock-quill MK 4 ︱quill stroke 150 mm︱tailstock travel 580 mm︱drive capacity - spindle motor 28 / 21 kW︱voltage 400 V︱total power requirement 44 kVA︱
          - Serial-No. 01360007501 - Machine ON: 28.932 h - Program ON: 9.315 h - C-Axis and Revolver for driven tools - control: SIEMENS Sinumerik 840D ShopTurn - chip conveyor - div. tool holder - coolant equipment - machine lamp
            turning diameter 320 mm
            turning length 600 mm
            control Sinumerik 840 D Shop Turn
            C - Axis main spindle 0,04 °
            driven Tools 4.500 U/min
            3-jaw-chuck diameter 215 mm
            swing diameter 505 mm
            bar diameter 75 mm
            travel -z axis 635 mm
            travel -x axis 250 mm
            rapid travel - longitudinal/face 24 / 30 m/min
            spindle speed: 25 - 5000 1/min
            spindle bore 87 mm
            turret head 12 Pos. VDI 30
            taper in tailstock-quill MK 4
            quill stroke 150 mm
            tailstock travel 580 mm
            drive capacity - spindle motor 28 / 21 kW
            voltage 400 V
            total power requirement 44 kVA
            Description :
            - Serial-No. 01360007501
            - Machine ON: 28.932 h
            - Program ON: 9.315 h
            - C-Axis and Revolver for driven tools
            - control: SIEMENS Sinumerik 840D
            ShopTurn
            - chip conveyor
            - div. tool holder
            - coolant equipment
            - machine lamp
          Datasheet
          Request / Contact
          used  CNC Turning- and Milling Center GILDEMEISTER CTX 420 linear / Sinumerik 840


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20189 · CNC Turning- and Milling Center

          GILDEMEISTER - CTX 420 linear / Sinumerik 840 - - 2006 - SINUMERIK 840D ShopTurn

          Technical details
          turning diameter 324 mm︱turning length 600 mm︱control SINUMERIK 840D ShopTurn︱swing diameter 680 mm︱bar diameter 65 mm︱travel -x axis 260 mm︱travel -z axis 635 mm︱spindle speed: 5000 1/min︱spindle bore 79 mm︱C-Axis 0,025 °︱turret head 12 Pos. / VDI 40︱Driven Tools 12 Pos. 4.500 U/min︱rapid traverse X-axis 60 m/min︱rapid traverse Z-axis 45 m/min︱taper in tailstock-quill MK 5 ︱tailstock travel 580 mm︱drive capacity - spindle motor 25 kW︱voltage 400 V︱total power requirement 50 kVA︱weight of the machine ca. 6,0 t︱
          - Serial-No.: 02260006321 - Machine ON: 51.091 h - Programm ON: 16.863 h - electrical hand wheel - C-Axis / driven tools - chip conveyor - coolant equipment - machine lamp
            turning diameter 324 mm
            turning length 600 mm
            control SINUMERIK 840D ShopTurn
            swing diameter 680 mm
            bar diameter 65 mm
            travel -x axis 260 mm
            travel -z axis 635 mm
            spindle speed: 5000 1/min
            spindle bore 79 mm
            C-Axis 0,025 °
            turret head 12 Pos. / VDI 40
            Driven Tools 12 Pos. 4.500 U/min
            rapid traverse X-axis 60 m/min
            rapid traverse Z-axis 45 m/min
            taper in tailstock-quill MK 5
            tailstock travel 580 mm
            drive capacity - spindle motor 25 kW
            voltage 400 V
            total power requirement 50 kVA
            weight of the machine ca. 6,0 t
            Description :
            - Serial-No.: 02260006321
            - Machine ON: 51.091 h
            - Programm ON: 16.863 h
            - electrical hand wheel
            - C-Axis / driven tools
            - chip conveyor
            - coolant equipment
            - machine lamp
          Datasheet
          Request / Contact
          used  CNC Turning- and Milling Center BOLEY BC 32


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-19326 · CNC Turning- and Milling Center

          BOLEY - BC 32 - - 1998 - MELDAS M 635 LC MITSUBISHI

          Technical details
          turning diameter 32 mm︱turning length 80 mm︱control MELDAS M 635 LC MITSUBISHI︱C-Axis 0,001 °︱bar diameter 32 mm︱bar length 3000 mm︱spindle bore 35 mm︱travel -x axis 130 mm︱travel -z axis 200 mm︱travel -z axis (sub spindle) 400 mm︱spindle speed main spindle 80 - 8000 1/min︱spindle speed sub spindle 60 - 6000 1/min︱Driven Tools 45 - 4500 1/min︱tool taper VDI 20 DIN 69880︱rapid traverse 24 m/min︱turret head 12 Pos.︱drive capacity - spindle motor 3,7 / 5,5 kW︱voltage 400 V︱total power requirement 12 kW︱weight of the machine ca. 2,0 t︱
          - S/N: 85015 - MITSUBISHI MELDAS M 635 LC control - sub spindle, part catcher - C-axis with an Indexing of 0,001 mm - 41.957 power-on-hour
            turning diameter 32 mm
            turning length 80 mm
            control MELDAS M 635 LC MITSUBISHI
            C-Axis 0,001 °
            bar diameter 32 mm
            bar length 3000 mm
            spindle bore 35 mm
            travel -x axis 130 mm
            travel -z axis 200 mm
            travel -z axis (sub spindle) 400 mm
            spindle speed main spindle 80 - 8000 1/min
            spindle speed sub spindle 60 - 6000 1/min
            Driven Tools 45 - 4500 1/min
            tool taper VDI 20 DIN 69880
            rapid traverse 24 m/min
            turret head 12 Pos.
            drive capacity - spindle motor 3,7 / 5,5 kW
            voltage 400 V
            total power requirement 12 kW
            weight of the machine ca. 2,0 t
            Description :
            - S/N: 85015
            - MITSUBISHI MELDAS M 635 LC control
            - sub spindle, part catcher
            - C-axis with an Indexing of 0,001 mm
            - 41.957 power-on-hour
          Datasheet
          Request / Contact

          Lathe - cycle-controlled

          used  Lathe -  cycle-controlled FAT-HACO - ueberholt TUR 1100 MN - 810D Shopturn


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20167 · Lathe - cycle-controlled

          FAT-HACO - ueberholt - TUR 1100 MN - 810D Shopturn - - 2006 - Sinumerik 810D Shopturn

          Technical details
          centre height 550 mm︱centre distance 2000 mm︱turning diameter over bed 1100 mm︱turning diameter over slide 790 mm︱turning length 2000 mm︱spindle taper D1-11 ︱control Sinumerik 810D Shopturn ︱bed width 622 mm︱spindle bore 140 mm︱turning speed range 4-300 / 160 - 1200 U/min︱feed: 0 - 6000 mm/min︱rapid travel - longitudinal/face 6 / 6 m/min︱powered chuck diameter 630 mm︱hollow clamping cylinder dia. 117,5 mm︱tool turret 8 Pos. Sauter︱drive capacity - spindle motor 37 kW︱taper in tailstock-quill MK 6 ︱dia. of quill 140 mm︱quill stroke 220 + 80 mm︱coolant
          Machine has life tools and spindle indexation 2,5° - Serial No.: 060559 - hydr. 3-Jaw power chuck Kitagawa dia.630 mm - hydr. quill on tail stock - indexing spindle every 2,5° - 8 Pos. tool turret for life tools (Sauter) Machine is being reconditioned at present. It will be ready for sale at approx. June 2020 Price subject to change until final completion of the reconditioning work.
            centre height 550 mm
            centre distance 2000 mm
            turning diameter over bed 1100 mm
            turning diameter over slide 790 mm
            turning length 2000 mm
            spindle taper D1-11
            control Sinumerik 810D Shopturn
            bed width 622 mm
            spindle bore 140 mm
            turning speed range 4-300 / 160 - 1200 U/min
            feed: 0 - 6000 mm/min
            rapid travel - longitudinal/face 6 / 6 m/min
            powered chuck diameter 630 mm
            hollow clamping cylinder dia. 117,5 mm
            tool turret 8 Pos. Sauter
            drive capacity - spindle motor 37 kW
            taper in tailstock-quill MK 6
            dia. of quill 140 mm
            quill stroke 220 + 80 mm
            Description :
            Machine has life tools and
            spindle indexation 2,5°
            - Serial No.: 060559
            - hydr. 3-Jaw power chuck Kitagawa dia.630 mm
            - hydr. quill on tail stock
            - indexing spindle every 2,5°
            - 8 Pos. tool turret for life tools (Sauter)
            Machine is being reconditioned at present.
            It will be ready for sale at approx. June 2020
            Price subject to change until
            final completion of the
            reconditioning work.
          Datasheet
          Request / Contact
          used  Lathe -  cycle-controlled HARRISON Alpha 400 T


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20166 · Lathe - cycle-controlled

          HARRISON - Alpha 400 T - - 2005 - FANUC

          Technical details
          centre height 195 mm︱centre distance 1250 mm︱turning diameter over bed 400 mm︱turning diameter over slide 245 mm︱turning dia. in gap 585 mm︱turning length 1250 mm︱spindle taper CAMLOCK KK 6 DIN 55029︱control FANUC ︱bed width 320 mm︱spindle bore 55 mm︱turning speed range 15 - 2500 U/min︱rapid travel - longitudinal/face 4 / 3 m/min︱quick change toolholder PARAT ︱drive capacity - spindle motor 7,7 kW︱taper in tailstock-quill MK 5 ︱dia. of quill 75 mm︱quill stroke 150 mm︱coolant ︱voltage 400 V︱total power requirement 11,0 kW︱
          - Serial-No.: D3D040/17 - control: FANUC - with live steady - fixed steady - 4-jaw chuck Ø 250 mm - coolant equipment
            centre height 195 mm
            centre distance 1250 mm
            turning diameter over bed 400 mm
            turning diameter over slide 245 mm
            turning dia. in gap 585 mm
            turning length 1250 mm
            spindle taper CAMLOCK KK 6 DIN 55029
            control FANUC
            bed width 320 mm
            spindle bore 55 mm
            turning speed range 15 - 2500 U/min
            rapid travel - longitudinal/face 4 / 3 m/min
            quick change toolholder PARAT
            drive capacity - spindle motor 7,7 kW
            taper in tailstock-quill MK 5
            dia. of quill 75 mm
            quill stroke 150 mm
            voltage 400 V
            total power requirement 11,0 kW
            Description :
            - Serial-No.: D3D040/17
            - control: FANUC
            - with live steady
            - fixed steady
            - 4-jaw chuck Ø 250 mm
            - coolant equipment
          Datasheet
          Request / Contact
          used  Lathe -  cycle-controlled KERN CD 800


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20241 · Lathe - cycle-controlled

          KERN - CD 800 - - 2002 - Manual Plus 4110 HEIDENHAIN

          Technical details
          centre height 410 mm︱centre distance 3000 mm︱turning diameter over bed 800 mm︱turning diameter over slide 530 mm︱bed width 485 mm︱spindle taper KK 11 DIN 55027︱control Manual Plus 4110 HEIDENHAIN︱spindle bore 106 mm︱turning speed range 1-1800 U/min︱feed: 2000 / 1000 mm/min︱rapid travel - longitudinal/face 10/5 m/min︱3-jaw-chuck diameter 500 mm︱tool turret 8 Pos. VDI 50︱drive capacity - spindle motor 37 kW︱taper in tailstock-quill MK 6 ︱dia. of quill 115 mm︱quill stroke 225 mm︱voltage 400 V︱total power requirement 46 kW︱weight of the machine ca. 9,5 t︱
          - Serial-no.: 5203.02 - control: HEIDENHAIN Manual Plus 4110 - Revolver SAUTER with 8 Positions - fixed steady - with live steady - chip conveyor - band filter unit - coolant equipment
            centre height 410 mm
            centre distance 3000 mm
            turning diameter over bed 800 mm
            turning diameter over slide 530 mm
            bed width 485 mm
            spindle taper KK 11 DIN 55027
            control Manual Plus 4110 HEIDENHAIN
            spindle bore 106 mm
            turning speed range 1-1800 U/min
            feed: 2000 / 1000 mm/min
            rapid travel - longitudinal/face 10/5 m/min
            3-jaw-chuck diameter 500 mm
            tool turret 8 Pos. VDI 50
            drive capacity - spindle motor 37 kW
            taper in tailstock-quill MK 6
            dia. of quill 115 mm
            quill stroke 225 mm
            voltage 400 V
            total power requirement 46 kW
            weight of the machine ca. 9,5 t
            Description :
            - Serial-no.: 5203.02
            - control: HEIDENHAIN Manual Plus 4110
            - Revolver SAUTER with 8 Positions
            - fixed steady
            - with live steady
            - chip conveyor
            - band filter unit
            - coolant equipment
          Datasheet
          Request / Contact
          used  Lathe -  cycle-controlled BOEHRINGER VDF DUS 560 ti


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20294 · Lathe - cycle-controlled

          BOEHRINGER - VDF DUS 560 ti - - 2001 - Sinumerik 810 D SIEMENS

          Technical details
          centre height 280 mm︱centre distance 1800 mm︱turning diameter over bed 570 mm︱turning diameter over slide 365 mm︱turning length 1500 mm︱spindle taper KK 8 DIN 55027︱control Sinumerik 810 D SIEMENS︱bed width 360 mm︱spindle bore 62 mm︱turning speed range 3 - 2500 U/min︱feed: 5000 mm / min︱rapid travel - longitudinal/face 10 m/min︱3-jaw-chuck diameter 315 mm︱quick change toolholder CAPTO / MULTIFIX Typ C Kombi︱drive capacity - spindle motor 25 kW︱taper in tailstock-quill MK 5 ︱dia. of quill 100 mm︱quill stroke 190 mm︱coolant ︱voltage 400 V︱
          - Serial-No.: 2022 383303 - control: SIEMENS Sinumerik 810 D - rapid traverse - 3-jaw-self-centering wedge bar Chuck SCHUNK - quick change tool holder-Kombination CAPTO / MULTIFIX Typ C - chip conveyor - coolant equipment - machine lamp
            centre height 280 mm
            centre distance 1800 mm
            turning diameter over bed 570 mm
            turning diameter over slide 365 mm
            turning length 1500 mm
            spindle taper KK 8 DIN 55027
            control Sinumerik 810 D SIEMENS
            bed width 360 mm
            spindle bore 62 mm
            turning speed range 3 - 2500 U/min
            feed: 5000 mm / min
            rapid travel - longitudinal/face 10 m/min
            3-jaw-chuck diameter 315 mm
            quick change toolholder CAPTO / MULTIFIX Typ C Kombi
            drive capacity - spindle motor 25 kW
            taper in tailstock-quill MK 5
            dia. of quill 100 mm
            quill stroke 190 mm
            voltage 400 V
            Description :
            - Serial-No.: 2022 383303
            - control: SIEMENS Sinumerik 810 D
            - rapid traverse
            - 3-jaw-self-centering wedge bar Chuck SCHUNK
            - quick change tool holder-Kombination
            CAPTO / MULTIFIX Typ C
            - chip conveyor
            - coolant equipment
            - machine lamp
          Datasheet
          Request / Contact

          Mechanician s Lathe

          used  Mechanician s Lathe GROENEWEGEN Gromatic


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-19179 · Mechanician s Lathe

          GROENEWEGEN - Gromatic - - -

          Technical details
          turning diameter over bed 280 mm︱turning diameter over slide rest 160 mm︱turning length 500 mm︱center height over bed 140 mm︱bed width 170 mm︱spindle bore Ø 28 mm︱turning speed range 76 - 960 U/min︱power capacity 0,6 kW︱3-jaw-chuck diameter 130 mm︱voltage 380 V︱total power requirement 0,6 kW︱weight of the machine ca. 500 kg︱
          - S/N: 72530 - without tailstock
            turning diameter over bed 280 mm
            turning diameter over slide rest 160 mm
            turning length 500 mm
            center height over bed 140 mm
            bed width 170 mm
            spindle bore Ø 28 mm
            turning speed range 76 - 960 U/min
            power capacity 0,6 kW
            3-jaw-chuck diameter 130 mm
            voltage 380 V
            total power requirement 0,6 kW
            weight of the machine ca. 500 kg
            Description :
            - S/N: 72530
            - without tailstock
          Datasheet
          Request / Contact
          used  Mechanician s Lathe WEILER


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-19236 · Mechanician s Lathe

          WEILER - - - -

          Technical details
          turning diameter over bed 250 mm︱turning diameter over slide rest 110 mm︱turning length 350 mm︱center height over bed 125 mm︱centre distance 350 mm︱bed width 170 mm︱spindle bore 24 mm︱turning speed range 440 - 3600 U/min︱voltage 380 V︱weight of the machine ca. 350 kg︱dimensions of the machine ca. 1,25 x 0,55 x 1,25 m︱
          - revolver 5-fold - Collet equipment
            turning diameter over bed 250 mm
            turning diameter over slide rest 110 mm
            turning length 350 mm
            center height over bed 125 mm
            centre distance 350 mm
            bed width 170 mm
            spindle bore 24 mm
            turning speed range 440 - 3600 U/min
            voltage 380 V
            weight of the machine ca. 350 kg
            dimensions of the machine ca. 1,25 x 0,55 x 1,25 m
            Description :
            - revolver 5-fold
            - Collet equipment
          Datasheet
          Request / Contact

          Bench Drilling Machine

          used  Bench Drilling Machine OPTIMUM B 24 H Vario


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-B24HVar · Bench Drilling Machine

          OPTIMUM - B 24 H Vario - - NEU -

          Technical details
          bore capacity in steel (diameter) 24 mm︱throat 165 mm︱bore stroke 85 mm︱table surface area 280 x 300 mm︱spindle taper MT 2 ︱spindle turning speed - stepless 100 - 5950 U/min︱voltage 230 V︱total power requirement 1,5 kW︱weight of the machine ca. 85 kg︱dimensions of the machine ca. 0,45 x 0,65 x 1,00 m︱
          - Infinitely variable speed - Keyless drill chuck 1-16 mm
            bore capacity in steel (diameter. 24 mm
            throat 165 mm
            bore stroke 85 mm
            table surface area 280 x 300 mm
            spindle taper MT 2
            spindle turning speed - stepless 100 - 5950 U/min
            voltage 230 V
            total power requirement 1,5 kW
            weight of the machine ca. 85 kg
            dimensions of the machine ca. 0,45 x 0,65 x 1,00 m
            Description :
            - Infinitely variable speed
            - Keyless drill chuck 1-16 mm
          Datasheet
          Request / Contact
          used  Bench Drilling Machine MAXION BT 13


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-19806 · Bench Drilling Machine

          MAXION - BT 13 - - -

          Technical details
          bore capacity in steel (diameter) 13 mm︱throat 180 mm︱bore stroke 70 mm︱table surface area 235 x 170 mm︱workpiece height max. 550 mm︱spindle taper MT 2 ︱spindle turning speed range 480 - 4000 U/min︱voltage 400 V︱total power requirement 0,45 kW︱weight of the machine ca. 158 kg︱dimensions of the machine ca. 0,80 x 0,55 x 1,90 m︱
          - Serial-No.: 162276
            bore capacity in steel (diameter. 13 mm
            throat 180 mm
            bore stroke 70 mm
            table surface area 235 x 170 mm
            workpiece height max. 550 mm
            spindle taper MT 2
            spindle turning speed range 480 - 4000 U/min
            voltage 400 V
            total power requirement 0,45 kW
            weight of the machine ca. 158 kg
            dimensions of the machine ca. 0,80 x 0,55 x 1,90 m
            Description :
            - Serial-No.: 162276
          Datasheet
          Request / Contact

          Machining Center - Universal

          used  Machining Center - Universal DMG DMU 60 T Monoblock - iTNC 530


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20284 · Machining Center - Universal

          DMG - DMU 60 T Monoblock - iTNC 530 - - 2002 -

          Technical details
          x-travel 630 mm︱y-travel 560 mm︱z-travel 560 mm︱CNC-control iTNC 530 HEIDENHAIN︱Table dimensions 1000 x 600 mm︱max. table load 800 kg︱spindle taper SK 40 ︱spindle turning speed range 20 - 12.000 U/min︱feed range 20 - 10.000 mm/min︱rapid traverse 26 m/min︱tool change unit 24 Pos.︱coolant ︱chip conveyor Spiralförderer ︱voltage 400 V︱total power requirement 26 kVA︱weight 6,5 t︱dimensions of the machine ca. 2,20 x 3,80 x 2,20 m︱coolant tank 1,20 x 0,60 x 1,00 m︱
          - Serial-No.: 11120008383 - control: iTNC 530 - Machine ON: 80.271 h - Program ON: 40.774 h - electrical hand wheel - Spiral conveyor
            x-travel 630 mm
            y-travel 560 mm
            z-travel 560 mm
            CNC-control iTNC 530 HEIDENHAIN
            Table dimensions 1000 x 600 mm
            max. table load 800 kg
            spindle taper SK 40
            spindle turning speed range 20 - 12.000 U/min
            feed range 20 - 10.000 mm/min
            rapid traverse 26 m/min
            tool change unit 24 Pos.
            chip conveyor Spiralförderer
            voltage 400 V
            total power requirement 26 kVA
            weight 6,5 t
            dimensions of the machine ca. 2,20 x 3,80 x 2,20 m
            coolant tank 1,20 x 0,60 x 1,00 m
            Description :
            - Serial-No.: 11120008383
            - control: iTNC 530
            - Machine ON: 80.271 h
            - Program ON: 40.774 h
            - electrical hand wheel
            - Spiral conveyor
          Datasheet
          Request / Contact
          used  Machining Center - Universal DMG  (5-Achsen) DMU 80 T - iTNC 530


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20310 · Machining Center - Universal

          DMG (5-Achsen) - DMU 80 T - iTNC 530 - - 2002 - iTNC 530 HEIDENHAIN

          Technical details
          x-travel 880 mm︱y-travel 630 mm︱z-travel 630 mm︱control iTNC 530 HEIDENHAIN︱Table dimensions 1250 x 700 / Ø 700 mm︱max. table load 500 kg︱spindle taper BT 40 ︱spindle turning speed range 20 - 12.000 U/min︱feed range 15.000 mm/min︱rapid traverse 30 m/min︱tool change unit 32 Pos.︱coolant ︱chip conveyor Spiralförderer ︱voltage 400 V︱total power requirement 54 kVA︱weight 8,0 t︱dimensions of the machine ca. 2,30 x 4,45 x 2,40 m︱coolant tank 1,10 x 0,55 x 1,10 m︱
          - serial-no.:11130003913 - 5-axis (simultaneous) control - Machine ON: 32.557 h - program run: 12.906 h - electronic hand wheel - screw type chip conveyor - coolant equipment - new bearings for rotary table gear box and new table sealings
            x-travel 880 mm
            y-travel 630 mm
            z-travel 630 mm
            control iTNC 530 HEIDENHAIN
            Table dimensions 1250 x 700 / Ø 700 mm
            max. table load 500 kg
            spindle taper BT 40
            spindle turning speed range 20 - 12.000 U/min
            feed range 15.000 mm/min
            rapid traverse 30 m/min
            tool change unit 32 Pos.
            chip conveyor Spiralförderer
            voltage 400 V
            total power requirement 54 kVA
            weight 8,0 t
            dimensions of the machine ca. 2,30 x 4,45 x 2,40 m
            coolant tank 1,10 x 0,55 x 1,10 m
            Description :
            - serial-no.:11130003913
            - 5-axis (simultaneous) control
            - Machine ON: 32.557 h
            - program run: 12.906 h
            - electronic hand wheel
            - screw type chip conveyor
            - coolant equipment
            - new bearings for rotary table
            gear box and new table sealings
          Datasheet
          Request / Contact
          used  Machining Center - Universal MIKRON (5-Achsen) UCP 600 / iTNC 530


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20255 · Machining Center - Universal

          MIKRON (5-Achsen) - UCP 600 / iTNC 530 - - 12/2006 - iTNC 530 HEIDENHAIN

          Technical details
          x-travel 530 mm︱y-travel 450 mm︱z-travel 450 mm︱control iTNC 530 HEIDENHAIN︱Table dimensions Ø 280 mm︱max. table load 200 kg︱spindle taper SK 40 ︱spindle turning speed range 12.000 U/min︱feed range 15.000 mm/min︱rapid traverse 22 m/min︱tool change unit 30 Pos.︱voltage 400 V︱total power requirement 44 kVA︱weight of the machine ca. 6,5 t︱dimensions of the machine ca. 1,65 x 3,30 x 1,65 m︱coolant 1,80 x 0,90 x 1,35 m︱chip conveyor 2,70 x 0,60 x 1,20 m︱
          - Factory No.: 107.32.99.204 - Program ON: 27.271 h - Spindle ON: 13,548 h - Control: iTNC 530 - RENISHAW TS27R for Tool measurement - RENISHAW OMP infrared measuring probe - electr. handwheel - Internal coolant supply through spindle with belt filter system - chip conveyor - div. tool holder
            x-travel 530 mm
            y-travel 450 mm
            z-travel 450 mm
            control iTNC 530 HEIDENHAIN
            Table dimensions Ø 280 mm
            max. table load 200 kg
            spindle taper SK 40
            spindle turning speed range 12.000 U/min
            feed range 15.000 mm/min
            rapid traverse 22 m/min
            tool change unit 30 Pos.
            voltage 400 V
            total power requirement 44 kVA
            weight of the machine ca. 6,5 t
            dimensions of the machine ca. 1,65 x 3,30 x 1,65 m
            coolant 1,80 x 0,90 x 1,35 m
            chip conveyor 2,70 x 0,60 x 1,20 m
            Description :
            - Factory No.: 107.32.99.204
            - Program ON: 27.271 h
            - Spindle ON: 13,548 h
            - Control: iTNC 530
            - RENISHAW TS27R for
            Tool measurement
            - RENISHAW OMP infrared measuring probe
            - electr. handwheel
            - Internal coolant supply through
            spindle with belt filter system
            - chip conveyor
            - div. tool holder
          Datasheet
          Request / Contact

          Machining Center - Vertical

          used  Machining Center - Vertical POSMILL B 800


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20304 · Machining Center - Vertical

          POSMILL - B 800 - - 2014 -

          Technical details
          x-travel 800 mm︱y-travel 510 mm︱z-travel 630 mm︱CNC-control AI 100 FANUC︱table-size 950 x 510 mm︱max. table load 500 kg︱spindle taper SK 40 ︱spindle turning speed range 12.000 U/min︱feed stepless 1 - 10.000 mm/min︱rapid traverse 30 m/min︱tool change unit 24 Pos.︱coolant IKZ ︱chip conveyor Spiralförderer ︱voltage 400 V︱total power requirement 25 kVA︱weight of the machine ca. 6,0 t︱dimensions of the machine ca. 2,65 x 2,30 x 2,35 m︱coolant tank 2,00 x 0,80 x 0,50 m︱coolant tank 2,45 x 0,45 x 0,35 m︱internal coolant system feed 0,55 x 0,45 x 0,85 m︱
          - Serial-No.: 20140605 - Machine ON: 15.258 h - control: FANUC AI 100 - Internal coolant supply through spindle - Spiral chip conveyor - electr. handwheel - spindle cooler - network connection - div. tool holder - main spindle with new bearings!
            x-travel 800 mm
            y-travel 510 mm
            z-travel 630 mm
            CNC-control AI 100 FANUC
            table-size 950 x 510 mm
            max. table load 500 kg
            spindle taper SK 40
            spindle turning speed range 12.000 U/min
            feed stepless 1 - 10.000 mm/min
            rapid traverse 30 m/min
            tool change unit 24 Pos.
            coolant IKZ
            chip conveyor Spiralförderer
            voltage 400 V
            total power requirement 25 kVA
            weight of the machine ca. 6,0 t
            dimensions of the machine ca. 2,65 x 2,30 x 2,35 m
            coolant tank 2,00 x 0,80 x 0,50 m
            coolant tank 2,45 x 0,45 x 0,35 m
            internal coolant system feed 0,55 x 0,45 x 0,85 m
            Description :
            - Serial-No.: 20140605
            - Machine ON: 15.258 h
            - control: FANUC AI 100
            - Internal coolant supply through spindle
            - Spiral chip conveyor
            - electr. handwheel
            - spindle cooler
            - network connection
            - div. tool holder
            - main spindle with new bearings!
          Datasheet
          Request / Contact
          used  Machining Center - Vertical MTRENT V 60 D


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20223 · Machining Center - Vertical

          MTRENT - V 60 D - - 2012 -

          Technical details
          x-travel 600 mm︱y-travel 420 mm︱z-travel 450 mm︱CNC-control TNC 620 HEIDENHAIN︱table-size 750 x 420 mm︱spindle taper SK 40 ︱spindle turning speed range 60 - 12000 U/min︱feed stepless 1 - 12.000 mm/min︱rapid traverse 32 m/min︱drive capacity - spindle motor 13 kW︱tool change unit 30 Pos.︱chip conveyor Spiralförderer ︱voltage 380 V︱total power requirement 30 kVA︱weight of the machine ca. 4,0 t︱dimensions of the machine ca. 2,20 x 2,75 x 2,30 m︱spindle oil cooler 1,05 x 0,65 x 1,10 m︱Coolant Tank 2,90 x 0,75 x 0,70 m︱Coolant Tank 1,95 x 0,80 x 0,50 m︱
          - Serial-No.: 121002 - Machine ON: 15.444 h - Spindle ON: 3.454 h - control: HEIDENHAIN TNC 620 - electrical hand wheel - 3D touch probe HEIDENHAIN TS 640 - chip conveyor - spindle oil cooler - coolant equipment
            x-travel 600 mm
            y-travel 420 mm
            z-travel 450 mm
            CNC-control TNC 620 HEIDENHAIN
            table-size 750 x 420 mm
            spindle taper SK 40
            spindle turning speed range 60 - 12000 U/min
            feed stepless 1 - 12.000 mm/min
            rapid traverse 32 m/min
            drive capacity - spindle motor 13 kW
            tool change unit 30 Pos.
            chip conveyor Spiralförderer
            voltage 380 V
            total power requirement 30 kVA
            weight of the machine ca. 4,0 t
            dimensions of the machine ca. 2,20 x 2,75 x 2,30 m
            spindle oil cooler 1,05 x 0,65 x 1,10 m
            Coolant Tank 2,90 x 0,75 x 0,70 m
            Coolant Tank 1,95 x 0,80 x 0,50 m
            Description :
            - Serial-No.: 121002
            - Machine ON: 15.444 h
            - Spindle ON: 3.454 h
            - control: HEIDENHAIN TNC 620
            - electrical hand wheel
            - 3D touch probe HEIDENHAIN TS 640
            - chip conveyor
            - spindle oil cooler
            - coolant equipment
          Datasheet
          Request / Contact
          used  Machining Center - Vertical RIMA RM 1000


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20005 · Machining Center - Vertical

          RIMA - RM 1000 - - 2010 -

          Technical details
          x-travel 1000 mm︱y-travel 560 mm︱z-travel 550 mm︱CNC-control FANUC oi-MD ︱table-size 1200 x 530 mm︱max. table load 800 kg︱spindle taper BT 40 ︱spindle turning speed range 10.000 U/min︱feed stepless 12.000 mm/min︱rapid traverse 30 m/min︱drive capacity - spindle motor 15 kW︱tool change unit 30 Pos.︱coolant IKZ ︱voltage 400 V︱total power requirement 35 kVA︱weight of the machine ca. 4,8 t︱dimensions of the machine ca. 3,40 x 2,35 x 2,75 m︱chip conveyor 4,30 x 1,65 x 1,65 m︱coolant 1,20 x 0,80 x 0,80 m︱
          - serial-no.: 102334003 - control: FANUC oi-MD - IKZ - ready for the 4 Axis - chip conveyor - Oilcooler
            x-travel 1000 mm
            y-travel 560 mm
            z-travel 550 mm
            CNC-control FANUC oi-MD
            table-size 1200 x 530 mm
            max. table load 800 kg
            spindle taper BT 40
            spindle turning speed range 10.000 U/min
            feed stepless 12.000 mm/min
            rapid traverse 30 m/min
            drive capacity - spindle motor 15 kW
            tool change unit 30 Pos.
            coolant IKZ
            voltage 400 V
            total power requirement 35 kVA
            weight of the machine ca. 4,8 t
            dimensions of the machine ca. 3,40 x 2,35 x 2,75 m
            chip conveyor 4,30 x 1,65 x 1,65 m
            coolant 1,20 x 0,80 x 0,80 m
            Description :
            - serial-no.: 102334003
            - control: FANUC oi-MD
            - IKZ
            - ready for the 4 Axis
            - chip conveyor
            - Oilcooler

          Datasheet
          Request / Contact
          used  Machining Center - Vertical HARDINGE - UNITECH VMC 1500P3 - CNC 810D Shopmill


          • Kirchgeorg Werkzeugmaschinen
          • Frankfurter Straße 141
          • 63303 Dreieich-Sprendlingen
          • Deutschland

          • 0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
          • info@kirchgeorg.de
            www.kirchgeorg.de
          #1072-20162 · Machining Center - Vertical

          HARDINGE - UNITECH - VMC 1500P3 - CNC 810D Shopmill - - 2007 -

          Technical details
          x-travel 1524 mm︱y-travel 660 mm︱z-travel 635 mm︱CNC-control Sinumerik 810D Shopmill︱table-size 1624 x 660 mm︱max. table load 1350 kg︱spindle taper BT-40 ︱spindle turning speed range 8000 U/min︱feed stepless 12000 mm/min︱rapid traverse 30 m/min︱drive capacity - spindle motor 16,4 kW︱tool change unit 32 Pos.︱coolant IKZ 20 bar ︱voltage 400 V︱total power requirement 46 kVA︱weight of the machine ca. 9,3 t︱dimensions of the machine ca. 3,97 x 2,52 x 2,85 m︱chip conveyor ca. 4,90 x 1,50 x 1,40 m︱
          - Serial-No.: NVEA7I0008 - Maschine in very good conditions - control: Siemens Sinumerik 810D Shopmill - Internal coolant 20 bar - chip conveyor
            x-travel 1524 mm
            y-travel 660 mm
            z-travel 635 mm
            CNC-control Sinumerik 810D Shopmill
            table-size 1624 x 660 mm
            max. table load 1350 kg
            spindle taper BT-40
            spindle turning speed range 8000 U/min
            feed stepless 12000 mm/min
            rapid traverse 30 m/min
            drive capacity - spindle motor 16,4 kW
            tool change unit 32 Pos.
            coolant IKZ 20 bar
            voltage 400 V
            total power requirement 46 kVA
            weight of the machine ca. 9,3 t
            dimensions of the machine ca. 3,97 x 2,52 x 2,85 m
            chip conveyor ca. 4,90 x 1,50 x 1,40 m
            Description :
            - Serial-No.: NVEA7I0008
            - Maschine in very good conditions
            - control: Siemens Sinumerik 810D Shopmill
            - Internal coolant 20 bar
            - chip conveyor
          Datasheet
          Request / Contact
          •
          •
          • 1
          • 2
          • 3
          • 4
          • 5
          • 6
          •
          •

            Профиль трейдера: Kirchgeorg Werkzeugmaschinen
          Ltd.

          Связаться с торговцем



            Инструменты Kirchgeorg машины
          Ltd.

           Frankfurter Straße 141
            63303 Dreieich-Sprendlingen
            Германия
            0049-(0)-6103-9909-0">0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
            info@kirchgeorg.de
            www.kirchgeorg.de

          Профиль пользователя Trader


          Компания Kirchgeorg Werkzeugmaschinen GmbH была основана в 1919 в Эрфурте, Тюрингия инженером Полом Кирхгером, в одном из старейших семейных новых и подержанных станков в Германии.

          Kirchgeorg начал свою деятельность как представитель и дилер по металлообрабатывающей и деревообрабатывающей технике, а также быстро превратил компанию в полный комплекс услуг по переоборудованию тяжелого оборудования, а также в торговлю станками и оборудованием.

          В 1953, в результате попыток экспроприации правительством Восточной Германии, Кирхгерг перенесли компанию в Фульду, Гессен в Западной Германии. В 1953 и 1960 к нему присоединились его сыновья Харро и Райнер соответственно, и компания вошла в еще одну фазу расширения.

          В 1960 первые здания были отрегулированы в нашем нынешнем месте в Драйайхе, и с тех пор они выросли и включают в себя квадратный метр 3,000 +.

          С Томасом Кирхгером, промышленным инженером, присоединившимся к компании в 2003, мы рады сообщить, что наш семейный бизнес находится в третьем поколении.

          Сегодня мы предлагаем больше, чем новые и подержанные станки 600 на выставке в Драйайхе. В дополнение к распространению по всему миру мы предлагаем индивидуальные, экспертные консультации и комплексное обслуживание. Мы также можем помочь вам получить финансирование, транспортировку, установку и обучение.

          На наших производственных объектах все использованные машины полностью восстановлены, тщательно протестированы и снабжены гарантией. Мы также производим запасные части, шестерни, редукторы и другие исполнительные модули.

          Наша дочерняя компания NASSOVIA Maschinenservice GmbH предоставляет авторизованные услуги для станков SIS EDMS Schiess-Nassovia с 1992.

          Мы являемся членом Немецкой ассоциации оптовых торговцев станками и станками (FDM).

          Склад 3000 sqm

          Мы более чем рады помочь вам с любыми вопросами. Мы с нетерпением ждем от вас ответа.


          Управляющие компанией

          Телефон
          Томас Кирчерг+ 49 (6103) 9909-23

          ПРОДАЖИ

          Телефон
          Норберт Дик+ 49 (6103) 9909-14

          Управление сбытом продукции

          Телефон
          Маттиас Гой+ 49 (6103) 9909-27

          Производственные технологии. управление

          Телефон
          Герд Брандт+ 49 (6103) 9909-17

          Бухгалтерский учет

          Телефон
          Мария Келблер+ 49 (6103) 9909-18

          Ресепшн

          Телефон
          Андре Милбрадт+ 49 (6103) 9909-0

          Веб-мастер
          Томас Кирчерг

          NASSOVIA Machine Service GmbH

          Телефон
          Ханс Беккер+ 49 (6103) 322693
          KIRCHGEORG
          Machine Tools GmbH

          Frankfurter Strasse 141
          D-63303 Dreieich

          Телефон + 49 (6103) 9909-0
          Факс + 49 (6103) 9909-50
          Электронная почта info@kirchgeorg.de

          Рабочие часы:
          Mon-Thu 7.30-16.30 CET
          Пятница 7.30-15.30 CET




          Kirchgeorg Werkzeugmaschinen GmbH  63303 Dreieich-Sprendlingen Frankfurter Straße 141 Deutschland
          Kirchgeorg Werkzeugmaschinen GmbH

          Frankfurter Straße 141



          Contact Trader


            Kirchgeorg Werkzeugmaschinen GmbH
           Frankfurter Straße 141
            63303 Dreieich-Sprendlingen
            Deutschland
            0049-(0)-6103-9909-0
            0049-(0)-6103-9909-50
            info@kirchgeorg.de
            www.kirchgeorg.de
            Contact person:
          Sehr geehrter Herr Thomas Kirchgeorg 0049-(0)-6103-9909-23
          Sehr geehrter Herr Norbert Dick 0049-(0)-6103-9909-14






          Machine category


          Abkantpresse - hydraulisch · Anreißplatte · Aufspannwinkel · Ausdrehkopf · Auswuchtmaschine · Bandschleifmaschine · Bandsäge - horizontal · Bandsäge - Vertikal · Bearbeitungszentrum - Universal · Bearbeitungszentrum - Vertikal · Bettfräsmaschine - Universal · Bohrerschleifmaschine · Buckelschweißmaschine · Bügelsäge · CNC Dreh- und Fräszentrum · CNC Drehmaschine - Schrägbettmaschine · Diaformgerät · Differenzwegpresse · Doppel-Gehrungsäge · Drahterodiermaschine · Dreh-,Schwenk-, und Kipptisch · Drehmaschine - zyklengesteuert · Eckverbindungsmaschinen · Exzenterpresse - Einständer · Flachschleifmaschine - Horizontal · Futter · Gewindeschneidmaschine · Gleitschleifanlage · Handhebel-Schere · Handspindelpresse · Hebegeräte · Hydraulische - Tafelschere · Hydraulische Presse · Härteofen · Industriesauger · Kaltkreissäge · Kantenfräsmaschine · Kolbenkompressor · Koordinatenmeßmaschine · Koordinatenschleifmaschine · Leit- und Zugspindeldrehmaschine · Lötanlage · Magnetspannplatte · Mechanikerdrehbank · Mehrspindel-Bohrkopf · Planscheibe · Plasmaschneidgerät · Pneumatische Presse · Polierbock · Profilprojektor · Profilstahlschere · Richtplatte · Rollenbahn · Rundschleifmaschine - Außen · Rundschleifmaschine - Universal · Rundtisch · Räummaschine - Innen - Vertikal · Schleifbock · Schraubstock · Schutzgasschweißanlage · Schwenkbiegemaschine · Stangenlader · Staubabsaugung · Stähleschleifmaschine · Säulenbohrmaschine · Säulenschwenkkran · Teilapparat · Tischbohrmaschine · Topfschleifmaschine · Tuschierplatte · Werkzeug Voreinstellgerät · Werkzeugfräsmaschine - Universal · Werkzeughalter · WIG-Schweißgerät · Würfeltisch · Zubehör/Sonstiges ·
