Band Saw - Vertical

roll diameter / mm︱throat / mm︱workpiece height / mm︱

---

With saw blade welder Mod: BSO Tape width: 16mm Volts: 360 Hz: 50-60 Amp: 5.2 Ap.No. 91622F Saw blade length max.: 4250mm Saw blade length min.: 4150mm Table dimension: 600x600mm Max working length: 1120mm

roll diameter / mm︱throat / mm︱workpiece height / mm︱

---

Table dimensions: 615x615mm

roll diameter 400 mm︱throat 420 mm︱workpiece height ca. 220 mm︱table-size 600 x 600 mm︱cutting speed 12 - 375 m/min︱saw band length 3160 - 3260 mm︱saw band width min./max. 3 - 12 mm︱total power requirement 3,6 kW︱weight of the machine ca. 0,55 t︱dimensions of the machine ca. 0,6 x 1,0 m︱Optical condition: very good ︱Mechanic: very good ︱

---

Overhaul year of construction 2023 400 V, 50 Hz, with CEE plug and cable Color: white/grey Accessories: * New castors * Emergency stop * Both doors electrically locked * Swivel table * Circuit diagram has been redrawn * Electrical acceptance certificate is enclosed On request, an LED light and a belt welding device can be installed for an additional charge Operating instructions, circuit diagram immediately available under chip ready for demonstration ! Accessories: * Machine overhauled in 2023 * New castors * Emergency stop * both doors electrically locked * Swivel table * Circuit diagram has been redrawn * Electrical acceptance certificate is enclosed An LED light can be installed on request for an additional charge Operating instructions, circuit diagram immediately available under chip ready for demonstration ! Operating instructions, circuit diagram immediately available under chip ready for demonstration !

417/320 mm︱ 600 mm︱ 300 mm︱ 600x500 mm︱ 3950 mm︱

---

Capacity 90º 230 mm︱Capacity 45º 190 mm︱

---

roll diameter 300 mm︱throat 300 mm︱workpiece height 156 mm︱table-size 500 x 500 mm︱total power requirement 0,75 kW︱weight of the machine ca. ca. 200 kg︱dimensions of the machine ca. 0,9 x 0,6 x 1,65 m︱saw band welder IDEAL BSO 16 ︱

---

table swivelabel +/- . °︱volt 400 V︱total power requirement 1,5 kW︱frequency 50 Hz︱

---

throat 355 mm︱workpiece height 230 mm︱table dimensions 500 x 400 mm︱cutting speed 20 - 90 m/min︱band length 2870 mm︱total power requirement - kW︱weight of the machine ca. 0,24 t︱dimensions of the machine ca. 1,06 x 0,50 x 1,85 m︱

---

roll diameter 500 mm︱throat 490 mm︱workpiece height 300 mm︱table-size 620 x 610 mm︱saw band length 3825 mm︱turning speeds 12 - 1900 m/min︱total power requirement kW︱weight of the machine ca. 0,4 t︱dimensions of the machine ca. 1,2 x 0,8 x 2,15 m︱

---

band saw with - swiveling table - Emergency stop device - 3-way foot switch - Machine light

15282 90 ︱band length 4600 - max. 4750 mm︱ Fabr. Ideal ︱weight ca. 890 kg︱dimensions of the machine ca. 130 x 850 x 2300 mm︱

---

roll diameter 420 mm︱throat 410 mm︱workpiece height 295 mm︱cutting speed 12 - 375 m/min︱table surface area 600 x 600 mm︱saw band length 3150-3260 // 3-16 mm︱work height max. 1020 mm︱voltage 380 V︱total power requirement 1,1 / 1,7 kW︱weight of the machine ca. 620 kg︱dimensions of the machine ca. 1000 x 800 x 1900 mm︱

---

** from a maintenance workshop - good condition (!!) Furnishing: - Butt welder IDEAL BSO / 16 with scissors and whetstone - 4 gear stages + 2 engine speeds - Belt guide height adjustment with handwheel - Working table tiltable +/-45° - Working table tiltable 10° - Machine base * Machinevideo : https://www.youtube.com/watch?v=UVpE_bLGHa0

roll diameter 500 mm︱throat 1050 / 485 mm︱workpiece height 300 mm︱saw band length 3920 - 4050 mm︱cutting speed 15 - 940 m/min︱table height 1040 mm︱table surface area 750 x 800 mm︱Table tiltable 15 Grad︱total power requirement 4 kW︱machine weight ab. 1.750 kg︱dimensions of the machine ca. 2100 x 1000 x 2100 mm︱

---

roll diameter mm︱throat mm︱workpiece height mm︱total power requirement kW︱weight of the machine ca. t︱required space m︱

---

throat: 485 bzw. 1050 mm
roller-Ø: 500 mm
Q7ewkq0z
passage height: 380 mm
table size: Arbeitstisch 780 x 800 mm
sawing band length: ueber 2 Laufraeder 3920 - 4050 mm
sawing band width max.: 20 mm
band speed: 15 - 940 m/min
engine: 380 V, 4 kW
space needed: 950 x 2130 x 2100 mm
weight: 1740 kg

Capacity round 45º - mm ø︱Capacity square 90º - mm︱Capacity square 60º - mm︱

---

Deep throat: 1.050 mm Saw speed: 15 - 2.300 m/min Variable adjustable speed Vertical band saw with roller table and welding machine

roll diameter / mm︱throat / mm︱workpiece height / mm︱table-size 600 x 600 mm︱weight of the machine ca. ca. 650 kg︱

---

Technical specifications: Roll diameter approx. 420mm Projection in width approx. 415mm Projection in height approx. 265mm Table size approx. 605 x 600 mm Belt speed 18 - 562 m/min. 8 levels Saw band length min./max. 3150 / 3260mm - Saw band speed over 4 gear stages and 2 engine speeds - Saw blade butt welder IDEAL BS 0-16 with scissors and whetstone - swiveling work table in 2 axes Dimensions: approx. L x W x H 950 mm x 750 mm x 1900 mm Weight 600kg with table feed Description has been adopted.

throat 420 mm︱workpiece height 250 mm︱table: 560 x 560 mm︱table - tiltable +/- 30°/10° rechts/links ︱weight of the machine ca. 0,8 t︱

---

Vertical band saw, Type: 8A531, year of manufacture: 1978, Manufacturer: Stanko Equipment: Welding and grinding device

table-size 670 x 670 mm︱throat 1030 mm︱workpiece height max. 300 mm︱saw band length min. 4700 mm︱saw band length max. 4800 mm︱sawing motor 2,2 kW︱total power requirement 3,2 kW︱weight of the machine ca. 1,0 t︱dimensions of machine L x W x H 2,31 x 1,05 x 2,03 m︱

---

Accessories: saw band welding and grinding attachment - table swivelling left / right - hydr. feed in table

roll diameter 500 mm︱throat 1050 / 485 mm︱workpiece height 300 mm︱saw band length 3920 - 4050 mm︱cutting speed 15 - 940 m/min︱table height 1040 mm︱table surface area 750 x 800 mm︱Table tiltable 15 Grad︱total power requirement 4,0 kW︱weight of the machine ca. 1750 kg︱dimensions of the machine ca. 2100 x 1000 x 2100 mm︱

---

- Fully automatic miter band saw - MAC 90 control - Saw feed infinitely adjustable via precision throttle - Infinitely adjustable clamping pressure - Infinitely variable speed adjustment of the saw band - hydraulic bundle clamping - chip conveyor - Cooling device - Micro dosing device - Machine light

roll diameter 500 mm︱throat 485 mm︱workpiece height mm︱total power requirement 2 kW︱weight of the machine ca. 1 t︱dimensions of the machine ca. m︱

---

roll diameter 400 mm︱throat 390 mm︱workpiece height 240 mm︱saw band length 2980 mm︱table surface area 500x600 mm︱weight of the machine ca. 350 kg︱dimensions of the machine ca. 650x1100x1700 mm︱

---

roll diameter 250 mm︱throat 3380 mm︱workpiece height mm︱throat 500 mm︱cutting speed 15 - 900 m/min︱table surface area 600 x 600 mm︱total power requirement 1,1 kW︱weight of the machine ca. 0,8 t︱dimensions of the machine ca. 1,0 x 0,8 x 2,1 m︱

---

4 rolls of 30 m saw band included.

roll diameter mm︱throat mm︱workpiece height mm︱total power requirement kW︱weight of the machine ca. t︱required space m︱

---

throat: 750/430 mm
roller-Ø: 350 mm
passage height: ca. 230 mm
table size: 520 x 520 + 480 x 250 mm
band speed: 50 - 300 feed/min
engine: 380 V, ca. 1,5 kW
space needed: 1730 x 880 x 1800 mm
V2lmuphiz
weight: ca. 500 kg

Wheel diameter 200 mm︱Cutting height 80 mm︱cutting width 180 mm︱Motor output 350 W︱Table dimensions mm︱Table tiltable 45 Grad︱saw band length 1400 x 6,5 x 0,35 mm︱machine weight ab. 12 kg︱Dimensions (L/W/H) 700 x 600 x 700 mm︱

---

Wood band saw with extendable and swiveling saw table

roll diameter 420 mm︱throat 400 mm︱workpiece height 285 mm︱cutting speed 15 - 1400 m/min︱table surface area 500 x 500 mm︱saw band length 3200-3400x6-20x0,9 mm︱work height max. 955 mm︱voltage 380 V︱total power requirement 1,5 kW︱weight of the machine ca. 470 kg︱dimensions of the machine ca. 950 x 750 x 1820 mm︱

---

Furnishing: - robust, vertical - band saw machine - Frequency-controlled, infinitely variable belt drive - Belt guide height adjustment with hand wheel - IDEAL strip welding machine model BSO, with shears and grinding motor - swiveling table 15°/45° - Machine base
